Xylem Flygt 2250 - Performance Curves

C
• with hose connection: 830-912 mm (32.67-35.9 in.)
• with threaded pipe connection: 847-935 mm
(33.34-36.81 in.)
Weight without motor cable: 540 kg (1,190 lbs)
Performance curves
Test standard
Pumps are tested in accordance with ISO 9906, HI level A.
2250.011
P1 [kW]
15
0
0 40 80 120 160 200 240 280
5
10
15
20
25
30
35
40
45
50
55
25
35
45
H [m]
Q [l/s]
WS006301A
Figure 5: 50 Hz, 1,470 rpm
P1 [kW] / [hp]
H [m] / [ft]
Q [usgpm] / [l/s]
40
0
0
0 50 100 150 200 250
1000 2000 3000 4000 5000
40
80
160
120
200
60
80
30
20
0
10
20
30
40
50
60
40
50
60
WS006302A
Figure 6: 60 Hz, 1,770 rpm
