• Statoil MedicWay 32
™
• BP Enerpar M 004
™
• Shell Ondina 927
™
• Shell Ondina X430
™
In applications where poisonous properties are of less concern, a mineral oil with viscosity
up to ISO VG32 can be used.
Empty the oil
1. Lay the pump on its side.
Lock the pump with supports to prevent it from rolling over.
2. Remove the oil screw.
CAUTION: Compressed Gas Hazard
Air inside the chamber may cause parts or liquid to be propelled with
force. Be careful when opening. Hold a rag over the plug to prevent
liquid from spraying out.
3. Turn the pump so that the oil hole faces downwards and let the oil run out into a
container.
WS002100A
Fill with oil
1. Replace the oil screw O-ring.
2. Turn the pump so that the oil hole faces upwards and fill with new oil.
Quantity: 0.17 L (0.18 qt)
3. Put the oil screw back and tighten it.
6.4 Replace the impeller
6 Maintenance
22 2008 Ready 8, 8S Installation, Operation, and Maintenance

Xylem Flygt Ready 4 Specifications

General

Protection Class	IP68
Insulation Class	F
Type	Submersible pump
Maximum liquid temperature	40 °C
Starting method	Direct on line
Motor cable	10 m
Frequency	50 Hz
