Xylem HYDROVAR HV 4.110 - 0700 Submenu Outputs

83
0700
0700 SUBMENU OUTPUTS
0705
0705 ANALOG OUT1
Output Frequency
Analogue output 1
Analogue output 0 – 10V = 0 - 100% Terminal: X3/20
Possible settings: - Actual value
- Output frequency (0 - fmax)
0710
0710 ANALOG OUT2
Actual value
Analogue output 2
Possible settings: Actual Value, Output frequency
Analogue output 4 – 20mA = 0 - 100% Terminal: X3/21
Possible settings: - Actual value
- Output frequency (0 - fmax)
0715
0715 CONF REL 1
Running
Configuration of the status relay 1 (X5/1-2-3)
0720
0720 CONF. REL 2
Errors
Configuration of the status relay 2 (X5/4-5-6)
Possible settings: Power, Errors, Warnings, StandBy, Errorreset, Errors of BASICs,
Warnings+BASICs
config. explanation of status Action if status=YES
Power HYDROVAR is connected to power supply
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Running Motor is running
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Errors
An error is indicated on the HYDROVAR
(incl. power failure)
Relay 1: X5/ 1-2 closed
Relay 2: X5/ 4-5 closed
Warnings A warning is indicated on the HYDROVAR
Relay 1: X5/ 1-2 closed
Relay 2: X5/ 4-5 closed
StandBy
Pump is released manually and by external release, no
error/warning is indicated and HYDROVAR doesn’t run
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Errorreset
If Parameter ERRORRESET [0615] is activated and a
Warning occurs 5 times -> Error ->
Relay 1: X5/ 1-3 closed
Relay 2: X5/ 4-6 closed
Error of
BASICs
A failure is indicated at least on one BASIC
Relay 1: X5/ 1-2 closed
Relay 2: X5/ 4-5 closed
Warnings
+ BASICs
A warning is indicated on the HYDROVAR or at least
on one BASIC
Relay 1: X5/ 1-2 closed
Relay 2: X5/ 4-5 closed
