Yaesu FTA-450L User Manual

FTA-450L OperATing MAnuAL
12
Before you BegIn
Battery Installation and Removal

To install the battery, insert the battery pack
SBR-
12LI
into the battery compartment on the back of
the
transceiver , press the end of the battery pack
while pressing the battery pack latch on the bot-
tom of the transceiver , then lock the pack by sliding
the locking plate beside the latch until the entire
“LOCK” appears .
Note:
Be sure that the rubber gasket on the
SBR-12LI
is
not loose when inserting.

To remove the battery, turn the
transceiver off, slide
the locking plate until the “UNLOCK” appears en-
tirely , lift up the end of the battery pack by pressing
the battery pack latch, then pull out the battery from
the radio.
PUSH
DATA
MIC/SP
EXT
DC
Battery Pack
Latch
Do not attempt to open any of the recharge-
able Lithium-ion packs, as personal injury
or damage to the Lithium-ion pack could occur if
a cell or cells become accidentally short-circuited.
Note:
To remove the battery pack after the belt clip
SHB-11
is mounted (see page 15), lift up the clip before you
press the battery pack latch.
