1033524A-3/15
Adjust box on top of car.
Measure from towers for reference.
IF POSSIBLE, POSITION BOX TO
AVOID INTERFERENCE WITH BACK
HATCH AND/OR SUNROOF.
OPEN LID TO GAIN ACCESS TO KNOBS.
Tighten knobs to
engage clamps.
TIGHTEN ALL
THUMB WHEELS.
• Check clamp opening for crossbar clearance.
• Loosen red knob further if necessary.
Slide clamps along tracks
(inside box) to engage crossbars.
To Next Page
