Tighten bolts while
pushing the end
clamps together.
REFER TO THE DRAWINGS BELOW
FOR BAR PLACEMENT,
or to
determine if the bar is required.
With a washer on the bolt, align the end
clamps to the hole in the bar. Thread the
bolts into the embedded nuts.
DO NOT COVER
JOINT SCREWS WITH END
CLAMPS.
ATTACH LOAD BAR WITH END CLAMPS.
BIKES
• Attach carrier at front of basket
and to load bar.
• Adjust the bar for load stability.
BOATS
• For shorter boats, attach accessory at front of
basket and to load bar.
• Longer loads, such as canoes or sea kayaks,
require the load bar to be removed.
SKIS
• Attach accessory at front of
basket and to load bar.
Short boat
utilizing LoadBar
Long loads may interfere
with LoadBar
Upright carrier
utilizing LoadBar
Fork style carrier
utilizing LoadBar
ACCESSORIES MUST BE ATTACHED TO THE FRONT OF THE BASKET (FRONT OF VEHICLE).
USE CAUTION WHEN
OPENING YOUR HATCH.
On some vehicles, hatch
interference is unavoidable.
ALWAYS TIE
DOWN LONG
LOADS TO FRONT
AND REAR OF
VEHICLE.
