IF YOUR CAR IS NOT LISTED in the Joe Fit Sheet
or the Fit List, call 888-925-4621 in the USA and Canada,
or see your dealer.
UNLISTED VEHICLES:
IF YOUR CAR CANNOT BE FOUND (on the Joe Fit Sheet or
the Fit List, or through the dealer or Yakima) it is “unlisted”.
Install the carrier as directed in these instructions where
this icon appears.
When you see this icon, find
your vehicle in the Joe Fit
Sheet for frame measurement,
strap positions, and critical
notes about your fit.
DANGER
DO NOT INSTALL THIS
CARRIER ON A VEHICLE
LISTED AS “NO FIT”.
FITTING YOUR CAR…
OR
CAUTION: Although your carrier is covered by a warranty (see
final page), Yakima cannot warranty any installation onto any
vehicle that is not listed in the Yakima Fit List or Joe Fit Sheet.
LOWER SUPPORT FRAME
UPPER
FRAME
To move the frames, pull and turn both
red triggers on the outer hubs.
LOAD ARMS
\
RED
TRIGGER
ROTATE THE UPPER FRAME.
Rotate the trigger
until it remains
pulled out.
FIND YOUR MEASUREMENT
IN THE FIT SHEET.
See FITTING YOUR CAR (above).
POSITION THE FRAMES.
measuring tape.
the frames apart.
MEASURE FROM THE
INSIDE EDGES OF THE
TUBES.
UNLISTED VEHICLES:
POSITION THE FRAMES.
Follow these guidelines to position your frames on your car.
UPPER FRAME
upper frame until it rests on
the vehicle.
the lower frame and will
depend on vehicle shape.
LOWER FRAME
occurs, choose another location.
CAUTIONS:
supported metal that will dent under weight.
CAUTION: Some vehicles have a spoiler. If
any part of the carrier contacts the spoiler,
do not use this product.
To Next Page
