Steering and Drive Axle Information
STEERING AXLE
Tonnage 2-3.5t
Type of Axle body Supported with Central Supporting Shaft
Steering angle Inner Side Wheel 78º
Outer Side Wheel 54º
King pin Center to Center of Kingpins 810mm (31.89 in)
Side Inclination Angle 0º
Wheel Camber Angle 1º
Wheel
Tonnage 2-2.5t 3-3.5t
Tire Drive 7.00-12-12 PR 28×9-15-14 PR
Steer 6.00-9-10 PR 6.50-10-10 PR
Rim Drive 5.00S-12 7.00T-15
Steer 4.00E-09 5.00F-10
Inflation Pressure Drive 860KPa (124.7 psi) 970KPa (140.7 psi)
Steer 860KPa (124.7 psi) 790KPa (114.6 psi)
Total Weight Around 115kg (253.5 lbs.) Around 140kg (308.6 lbs.)
Overview
The steering bridge is an open welded structure with
box cross-section (see Figure 22). It is composed of
the steering bridge body, the steering cylinder, the
connecting rod and the steering wheel. The steering
trapezoid adopts a crank slider mechanism. Before
and after the steering axle by pry to the frame at the
back of the pin shaft through the bearing bolt tail
frame, swing bridge fitness around the pin axis, around
the steering axle were about to have a steering
knuckle, wheel hub with two tapered roller bearings
after loaded on the steering shaft, wheel by pry to the
hub, rim inside of the bearing is equipped with oil seal,
keep the grease in the cavity between the wheel and
steering knuckle.
Steering and Drive Axle Information 8000 YRM 2199
24
