7
Installing Exterior Deadbolt
UP
Inside of Door
Confirm bolt is
retracted (unlocked).
!
Choose
through bolt
appropriate
for your door
thickness.
!
M6x44 PPHMS for standard door thickness shown
x2
13
P/N YRL-EMICL-256-KFTSINSTL-FUL Rev A
