1300 YRM 1330 Transaxle Assembly
Transaxle Assembly
REMOVE TRANSAXLE FROM FRAME
WARNING
The lift truck
must be put on blocks for some types
of maintenan
ce and transaxle repair. The removal
of the batter
y, mast, transaxle, or the counterweight
will cause la
rge changes in the center of gravity.
Position add
itional blocks under the frame when the
lift truck is
on blocks, so the lift truck cannot tip
over.
1. Remove mast
assembly.
See Mast Rep
air, 2- and 3-Stage High Visibility
Masts 4000 Y
RM 1386 for European lift truck mod-
els
• ERP15-20VT
(G807)
• ERP16-20VF
(A955)
See Mast Rep
air, 2-, 3-, And 4-Stage Heavy Duty
Masts 4000 Y
RM 1405 for European and American
lift truck m
odels
• ERP15-20VT
(ERP030-040VT) (G807)
• ERP16-20VF
(ERP30-40VF) (A955)
2. Tur n key sw i
tch to OFF position and disconnect bat-
tery.
3. Position li
ft truck frame on blocks so drive tires are
suspended o
ff the floor.
See Period
ic Maintenance 8000 YRM 1339 for lift
truck mode
ls
• ERP15-20V
T (ERP030-040VT) (G807)
See Period
ic Maintenance 8000 YRM 1373 for lift
truck mode
ls
• ERP16-20V
F (ERP30-40VF) (A955)
4. Remove driv
e tire lug nuts and drive tire and wheel
assembly.
5. Disconnec
t transaxle speed sensor connector from
main wirin
g harness.
6. Disconnec
t parking brake connector from main
wiring har
ness.
7. Disconnec
t manual override cable from parking
brakes.
8. Tag and disconnect power cables from traction mo-
tor studs.
9. Disconnect traction motor temperature sensor at
traction motor.
10. Disconnect service brake line from port on
transaxle. Cap brake line and plug port on transaxle
to reduce the possibility of contamination entering
brake system.
11. Loosen, but do not remove, five mounting cap-
screws and nuts that hold transaxle assembly on
lift truck.
WARNING
The transaxle and traction motor assemblies are
heavy. Be sure that all lifting devices are suitable
and of adequate capacity to lift the transaxle and
traction motor.
12. Position a floor jack under transaxle assembly.
Make sure assembly is properly balanced on floor
jack so it will not fall once mounting capscrews
have been removed.
CAUTION
Check that cables, hoses, and wires do not interfere
with the removal of the transaxle assembly.
13. Remove five capscrews and washers holding
transaxle on lift truck frame. Carefully lower
transaxle assembly from lift truck frame using floor
jack.
WARNING
The transaxle and traction motor assemblies are
heavy. Be sure that all lifting devices are suitable
and of adequate capacity to lift the transaxle and
traction motor.
14. Transfer transaxle assembly from floor jack to a
clean workbench using an appropriate sling and
overhead lifting device.
3
