Description
This section is written assuming no experience with
electronic controllers. The menu progressions indicate
how many key presses it will take to get to a given
screen, versus detailing out every screen you would
see. Refer to Table 1 for calibration procedures. Refer
to Table 2 for an example of how to read calibration
procedures.
NOTE: The calibration procedures described in this
YRM may have to be repeated when any on-board
controllers, sensors, or related components are
replaced.
Table 1. Calibration Procedures
When Procedure is Used:
Proc_Cal/Procedure All
Units
3
Functions
Electronic-
Hydraulic
Valves
4
Functions
Electronic-
Hydraulic
Valves
5
Functions
Electronic-
Hydraulic
Valves
Mazda Engine
w/Electronic 1-
Speed
Transmission
Units w/
Load
Weight
Display
Electronic
Transmission
(Basic & L1)
Electronic
Extended
Function
(L2)
001 Service Password
Entry
X
002 Hydraulic Valve
Calibration Warm Up and
Air Bleed
X X X
003 Save and Exit X
004 Lift Valve Output
Threshold
X X X
005 Lower Valve Output
Threshold
X X X
006 Tilt Back Valve Output
Threshold
X X X
007 Tilt Forward Valve
Output Threshold
X X X
008 Aux 1 Dir A Valve
Output Threshold
X X X
009 Aux 1 Dir B Valve
Output Threshold
X X X
010 Aux 2 Dir A Valve
Output Threshold
X X
011 Aux 2 Dir B Valve
Output Threshold
X X
012 Aux 3 Dir A Valve
Output Threshold
X
8000 YRM 1134 Description
Confidential/Proprietary - Do Not Copy or Duplicate 1
