PIR Motion Detector
• Mount in a position such that an intruder would
normally move across the PIRs eld of view.
• Height should be between 1.9 and 2 metres
above oor level.
• Location in a corner will ensure wider room
coverage.
• Do not mount the PIR where its eld of view will be
obstructed e.g. by curtains, ornaments etc.
• Do not point directly at sources of heat e.g. res or
boilers, and do not position directly
above radiators.
• Avoid mounting the PIR directly facing a window.
• Do not point the PIR at a door protected by a
Door/Window Contact.
Smoke Detector
• Mount in the middle of the ceiling at the top of a
stairwell, or on the centre of hallway ceilings where
smoke would most likely be detected.
• Do not mount in corners or above cooking
appliances and heaters.
• Install additional detectors if there are closed doors
preventing smoke from reaching detectors.
External Siren
Choose a position on an external wall where the
siren would be most prominent. Mount as high as
possible, out of easy reach.
Door/Window Contact
Select a door that will be the main point of entry and
exit, usually your front door.
• Mount as high as possible
• Do not aim a PIR at this door or window
Key Fob
Can be used inside or outside the property and can
be kept on your keyring.
Hub
• This Hub is the brain of your Alarm
System. All accessories wirelessly connect
to the Hub.
• Ensure it is hidden from view.
• Access to mains socket and broadband
internet router required.
