Yale PR3301 User Manual

Standard Frame
Notes:
Do Not Scale Drawing.
Left Hand Door Shown.
Same dimensions apply for Right Hand
Door measured from centerline of pivot point.
Dimensions are in inches (mm).
See Page 3 for A & B dimension values.
Standard Mount
Soffit Plate
Blade Stop Mount
293S Block
891 Block
Soffit Plate
5/8 Ref.
(16)
2-3/4
(70)
2
(51)
3/8
(10)
5/16*
(8)
1
(25)
2-1/16
(52)
7/16
(11)
*Use 9/16 (14) in openings
with blade stops.
C
L
Hinge or Pivot
12
(305)
3/4
(19)
3-1/4
(79)
B
A
Narrow Frame
Soffit Plate
890 Bracket
891 Block
Soffit Plate
5/8 Ref.
(16)
2-3/4
(70)
2
(51)
3/8
(10)
1
(25)
2-1/16
(52)
7/16
(11)
C
L
Hinge or
Pivot
12
(305)
3/4
(19)
3-1/4
(79)
3/4
(19)
1-1/4
(32)
890 Bracket
2 to 2-3/4
(51 to 70)
B
A
Flush Partition
Soffit Plate
2-1/2
(64)
1-1/2
(38)
1/2
(13)
3/4
(19)
C
L
Hinge or
Pivot
12
(305)
3/4
(19)
3-1/4
(79)
293L Angle
Bracket
1
(25)
B
A
Page 4

Yale PR3301 Specifications

General

Brand	Yale
Model	PR3301
Category	Door Opening System
Language	English
