Yale SV-4C-2ABFX User Manual

06
13) If you have only wired cameras in your Kit click NO.
(WiFi cameras can be added later if needed)
11) Click Refresh to update Network connection.
14) If you want access to your system via the Yale View App, scan
the QR code to connect to your DVR system.
(If not click NEXT)
15) Click NEXT
16) Click OK
12) Click NEXT
Initial setup for system with wired cameras.
The App needs to be installed
and registered before scanning.
The DVR system is now turned ON and
cameras are recording. System is as default
running in “Regular Mode”, which means
that cameras are recording 24 hours a day
and will overwrite the hard drive when full.
Other “Modes” and backing up recorded
video will be explained later in the manual.
Initial setup - Wired Kit
3

Yale SV-4C-2ABFX Specifications

General

Brand	Yale
Model	SV-4C-2ABFX
Category	Security System
Language	English
