5
P/N - - - Rev BYRL EMICL PBINSTL FUL
2
Installing Strike Plates
Door Frame
Inside
of Door
Frame
1" Dia. x
1"Deep
1" Dia. x
1/2"Deep
Frame
7-16 / 8-32 x 1" UNCWS
x4
