6B-11
Outboard Rigging Guide - 2001
6. Check:
• Throttle position sensor (TPS) output
voltage (at idle speed)
Out of specification → Refer to
“SERVICE MANUAL.”
NOTE:
Set the ditital tester to the manual range. In
the auto range the voltage changes cannot
be accurately measured.
Output voltage (P —O):
0.7 + 0.02V
Checking steps:
• Connect the test harness.
• Connect the tester leads to the test
harness (P —O).
• Start the engine and measure the volt-
age at engine idling speed.
E
To Next Page
