Yamaha 67C - Page 47

1-10
Outboard Rigging Guide - 2001 Rigging Kits
Tiller Handle Kit for F80/F100 (67G-W0086-Z1-4D)
Tiller Handle Kit for F115
Part Number Part Name Qty.
Tiller Kit Handle Ass’y1
Tiller Handle Install. Manual 1
6H2-82586-01-00 Wire Harness Extension 1
6H5-83553-11-00 Read Wire 1
90465-13M24-00 Clamp 1
90465-13M30-00 Clamp 1
688-83383-11-00 Buzzer 1
6H5-83386-00-00 Buzzer Stay 1
67G-42725-00-00 Grommet 1
97595-08530-00 Mark 1
62Y-82555-00-00 Damper Main Switch 1
67G-82554-00-00 Neutral Switch Ass’y1
67G-82555-01-00 Stay, Neutral Switch 1
Steering Friction Ass’y1
• 6E5-42518-01-00 • Shaft, Friction 1
• 92990-08600-00 • Plate Washer 2
• 67G-42528-00-00 • Piece, Friction 1
• 90175-06003-00 • Nut, Wing 1
• 97080-06035-00 • Bolt 1
• 6E5-42515-00-00 • Rod 1
• 90185-08057-00 • Nut, Lock 2
97595-06514-00 Bolt 2
63D-83720-00-00 Connector Ass’y. 1
Part Number Part Name Qty.
Tiller Kit Handle Ass’y1
Tiller Handle Install. Manual 1
63D-83728-00-00 Connector Ass’y. 1
688-82540-11-00 Neutral Switch Ass’y. 1
67G-82554-01-00 Stay, Neutral Switch 1
62Y-82555-00-00 Damper Main Switch 1
97595-06514-00 Bolt 1
97595-08530-00 Mark 1
67G-42725-00-00 Grommet 1
6H5-83553-11-00 Read Wire 1
63D-82586-00-00 Wire Harness Extension 1
688-83383-11-00 Buzzer 1
6H5-83386-00-00 Stay Buzzer 1
Steering Friction Ass’y1
• 6E5-42518-01-00 • Shaft Friction 1
• 92995-08600-00 • Plate Washer 1
• 67G-42528-00-00 • Piece, Friction 1
• 90175-06003-00 • Nut, Wing 1
• 97080-06035-00 • Bolt 1
• 6E5-42515-00-00 • Rod 1
• 90185-08057-00 • Nut, Lock 2
90465-13M30-00 Clamp 1
90465-13M24-00 Clamp 1
68V-42121-00-4D Bracket 1
90116-10175-00 Stud 2
90185-10051-00 Nylon Lock Nut 2
