Yamaha 90C - MAIN COMPONENTS OVERVIEW

E
2-1
EMU01206
MAIN COMPONENTS
q
!0
w
!3
!4
e
r
t
y
u
i
o
!2
!1
1 Top cowling
2 Top cowling lock lever
3 Anti-cavitation plate
4 Trim tab (Anode)
* 5 Propeller
6 Cooling water inlet
7 Anode
8 Trim angle adjusting rod
9 Clamp bracket
0 Tilt support lever
q Power trim and tilt switch
* w Flushing device
* e Remote control box
* r Digital tachometer
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
