Yamaha A3000 Upgrade Guide

Changes in MIDI Data Format
43
Appendix
Appendix
Changes in MIDI Data Format
Changes in MIDI data format under Version 2 are listed below.
3. Additional Realtime Messages
The following messages have been added. (☞ 353)
3.1.2 Timing clock, Start, Continue, Stop
If Program-LFO Sync is set to MIDI, the A3000 controls the LFO period and phase in
accordance with the following incoming realtime messages: timing clock (F8), start
(FA), continue (FB), and stop (FC).
5. Additional Yamaha System Exclusives
5.3. Parameter change
The following messages have been added. (☞ 357)
5.3.7. Object link change
0F0
143
2 nnnn = Device Number
358
404
5
↓upper object name (16 bytes)
20
21 upper object type
22
↓ lower object name (16 bytes)
37
38 lower object type
39 data (0:link off, 1:link on)
40 F7
This message changes the linking between the specified upper and lower objects (be-
tween program and sample, program and sample bank, or sample and sample bank).
The message will not do anything if the current state of either specified object does not
permit the link change, or if either object would need to be replicated to enable the link
change.
11110000
01000011
0001nnnn
01011000
00000100
0ccccccc
↓
0ccccccc
0ttttttt
0ccccccc
↓
0ccccccc
0ttttttt
0ddddddd
11110111
