Specifications
Digital Section
• Full Digital Signal Processing
• Mic Simulator: 8 Types
• Feedback Reduction: 5-band
• Digital Effects
• Limiter
• Digital Chorus, Digital Delay
• Hall Reverb, Room Reverb, Plate Reverb
• External Controller Function (EXP Pedal/MIDI): 8
Controllers/Parameters
• Tuner Function (Chromatic, Auto)
MIDI Functions
Receive: Program Change (Program Change Table
can be created), Control Change, Bulk In
Transmit: Program Change, Control Change, Bulk
Out, Merge Out
Guitar Power Supply
9V power can be supplied via a TRS phone cable
to a guitar’s built-in pre-amplifier, etc. that con-
sumes less than 10mA of power, and uses a mon-
aural output.
Controller/Switch
Top Panel
Push Switch x17
UP, DOWN, MANUAL, UTILITY, STORE, LIM-
ITER, FEEDBACK REDUCTION 1-5, CHO-
RUS, DELAY, HALL, ROOM, PLATE, SHIFT
Knob x15
MIC TYPE, BLEND, VOLUME, BASS,
MIDDLE, TREBLE, PRESENCE, LIMITER
LEVEL, FEEDBACK REDUCTION FREQ,
FEEDBACK REDUCTION DEPTH, CHORUS
SPEED/DELAY TIME, CHORUS DEPTH/DE-
LAY FEEDBACK, CHORUS LEVEL/DELAY
LEVEL, REVERB LEVEL, OUTPUT
Footswitch x4
1, 2, 3, BANK
Rear Panel
STAND-BY ON/OFF, MUTE, +9V SUPPLY ON/
OFF
Display
7 Segment LED (3 digit) x1
Push Switch LED x17
Footswitch LED x4
Connections
INPUT: Standard Stereo Phone Jack
OUTPUT L/MONO, R: Standard Stereo Phone Jack
(TRS Balanced)
PHONES: Standard Stereo Phone Jack
EXP. PEDAL: Standard Stereo Phone Jack
DIGITAL OUT: COAXIAL
MIDI IN, MIDI OUT: 5-pin DIN
A/D Converter
20 bit
D/A Converter
20 bit
Sampling Frequency
44.1kHz
Memory Allocations
Preset: 30
User: 30
Input Level/Impedance
(When using pre-amp bypass)
INPUT: -17 dBm / 1 MΩ
Output Level/Impedance
OUTPUT L/MONO: Balance +4 dBm / 600 Ω
OUTPUT R: Balance +4 dBm / 600 Ω
PHONES: 0 dBm / 47 Ω
Power
Exclusive Power Adaptor (AC-10)
AC Output: AC 12 V, 1 A
Power Consumption
15 W
Dimensions
280(W)x70(H)x184(D)mm (11.0"x2.8"x7.2")
Weight
2.2 kg (4lbs. 4oz.)
Accessories
Power Adaptor (AC-10)
TRS Phone Cable for Guitar Power Supply (3m)
TRS-XLR Converter Cable (x2)
Dummy Battery
Owner’s Manual (this booklet)
* Specifications and design may change without
notice.
