To Next PageTo Next PageWhat to do if my Yamaha AX-9 fails to turn on?
If your unit fails to turn on, first ensure that the power cord is firmly plugged in. Also, check that the IMPEDANCE SELECTOR switch on the rear panel is set to either end closely.
What to do if the sound suddenly goes off on my Yamaha Amplifier?
If the sound suddenly goes off, it could be due to the activation of the protection circuit because of a short circuit. Turning the unit into standby mode and then back on will reset the protection circuit. Alternatively, the SLEEP timer may have activated; try canceling the SLEEP timer function.
How to fix Yamaha Amplifier only one side speaker outputs the sound?
If sound is only coming from one speaker, check the BALANCE control and adjust it to the appropriate position. Also, incorrect cord connections can cause this issue, so ensure the cords are properly connected; if the problem continues, the cords may be defective.
Why is the remote control for my Yamaha AX-9 not working?
If the remote control is not working, it may be due to direct sunlight or lighting (like an inverter type of fluorescent lamp) striking the remote control sensor of the main unit. Try changing the position of the main unit.
Why does my Yamaha AX-9 Amplifier sound “hums”?
Humming sounds can occur due to incorrect cord connections. Ensure that the audio plugs are firmly connected; if the problem persists, the cords may be defective. Also, if you are using a turntable, make sure there is a GND connection between the turntable and the unit.
Why is the volume level low when playing a record on my Yamaha Amplifier?
If the volume level is low when playing a record, it could be because the record is being played on a turntable with an MC cartridge. In this case, the player should be connected to the unit through the MC head amplifier.
What to do if my Yamaha AX-9 does not work normally?
If the unit is not working normally, it may be due to strong external noise (lightning, excessive static electricity, etc.) or a misoperation. Turn the unit into standby mode and disconnect the AC power cord from the AC outlet. After about 30 seconds, reconnect the power and operate the unit again.
Why is the distance short for my Yamaha Amplifier remote control?
If the remote control's range is short, the batteries may be weak. Replace the batteries with new ones.
Why is there a lack of bass and no ambience from my Yamaha Amplifier?
A lack of bass and ambience can occur if the + and – wires are connected in reverse at the amplifier or speakers. Ensure that the speaker wires are connected in the correct phase (+ and –).
Why can't I increase the volume level or the sound is distorted on my Yamaha AX-9 Amplifier?
If the volume level cannot be increased or the sound is distorted, the component connected to the REC OUT terminals of this unit may be in standby mode. Turn the power to that component on.
General| Type | Integrated Amplifier |
|---|---|
| Power Output | 170 watts per channel into 8Ω (stereo) |
| Frequency Response | 20Hz to 20kHz |
| Signal-to-Noise Ratio | 110dB (line) |
| Input Impedance | 47k ohms |
| Damping Factor | 150 |
| Input Sensitivity | 2.5mV (MM), 150mV (line) |
| Channel separation | 70 dB (1kHz) |
| Dimensions | 435 x 165 x 448mm |
| Weight | 17kg |
| Total harmonic distortion | 0.003% |
| Speaker load impedance | 4Ω to 16Ω |
Detailed instructions for safe and optimal unit operation covering installation and general use.
Specific guidance for UK plug and mains wiring to ensure safety and compliance.
Critical warnings regarding impedance selector settings and power states to prevent damage.
Guide to properly connecting speaker wires to the unit's terminals.
