PERIODIC MAINTENANCE AND ADJUSTMENT
7-32
1
2
3
4
5
6
7
8
9
ing plate and the wheel by insert-
ing the wheel axle from the
right-hand side.
TIP
Make sure that the drive chain slack ad-
justing plate is installed with the
punched side facing to the outside.
2. Install the axle nut.
3. Install the brake rod onto the brake
camshaft lever, and then install the
brake pedal free play adjusting nut
onto the brake rod.
4. Connect the brake torque rod to
the brake shoe plate by installing
the brake torque rod bolt and the
brake torque rod nut, and then
tighten the nut to the specified
torque.
5. Insert a new cotter pin.
WARNING! Always use a new
cotter pin.
[EWA10831]
6. Adjust the drive chain slack. (See
page 7-19.)
7. Lower the rear wheel so that it is
on the ground.
8. Tighten the rear sprocket nut and
the axle nut to the specified
torques.
9. Adjust the brake pedal free play.
(See page 7-17.)
WARNING
EWA10660
After adjusting the brake pedal free
play, check the operation of the
brake light.
EAU25851
Troubleshooting
Although Yamaha motorcycles receive
a thorough inspection before shipment
from the factory, trouble may occur dur-
ing operation. Any problem in the fuel,
compression, or ignition systems, for
example, can cause poor starting and
loss of power.
The following troubleshooting chart
represents a quick and easy procedure
for checking these vital systems your-
self. However, should your motorcycle
require any repair, take it to a Yamaha
dealer, whose skilled technicians have
the necessary tools, experience, and
know-how to service the motorcycle
properly.
Use only genuine Yamaha replace-
ment parts. Imitation parts may look like
Yamaha parts, but they are often inferi-
or, have a shorter service life and can
lead to expensive repair bills.
WARNING
EWA15141
When checking the fuel system, do
not smoke, and make sure there are
no open flames or sparks in the ar-
ea, including pilot lights from water
Tightening torque:
Brake torque rod nut:
19 Nm (1.9 m·kgf, 14 ft·lbf)
Tightening torques:
Rear sprocket nut:
85 Nm (8.5 m·kgf, 61 ft·lbf)
Axle nut:
85 Nm (8.5 m·kgf, 61 ft·lbf)
