SPECIFICATIONS
EAU50970
Dimensions:
Overall length:
2110 mm (83.1 in)
Overall width:
930 mm (36.6 in)
Overall height:
1080 mm (42.5 in)
Seat height:
800 mm (31.5 in)
Wheelbase:
1315 mm (51.8 in)
Ground clearance:
235 mm (9.25 in)
Minimum turning radius:
2060 mm (81.1 in)
Weight:
Curb weight:
109 kg (240 lb)
Engine:
Engine type:
Air cooled 2-stroke
Cylinder arrangement:
Single cylinder
Displacement:
97 cm
3
Bore  stroke:
52.0  45.6 mm (2.05  1.80 in)
Compression ratio:
6.60 :1
Starting system:
Kickstarter
Lubrication system:
Separate lubrication (Yamaha autolube)
Engine oil:
Type:
YAMALUBE 2S or 2-stroke engine oil
(JASO FC grade)
Engine oil quantity:
Quantity:
1.50 L (1.59 US qt, 1.32 Imp.qt)
Transmission oil:
Type:
SAE 10W-30
Oil change quantity:
0.70 L (0.74 US qt, 0.62 Imp.qt)
Air filter:
Air filter element:
Wet element
Fuel:
Recommended fuel:
Unleaded gasoline only
Fuel tank capacity:
11.0 L (2.91 US gal, 2.42 Imp.gal)
Fuel reserve amount:
3.0 L (0.79 US gal, 0.66 Imp.gal)
Carburetor:
Type  quantity:
VM20SS x 1
Spark plug(s):
Manufacturer/model:
NGK/B7ES
Spark plug gap:
0.6–0.7 mm (0.024–0.028 in)
Clutch:
Clutch type:
Wet, multiple-disc
Transmission:
Primary reduction ratio:
4.529 (77/17)
Final drive:
Chain
Secondary reduction ratio:
3.643 (51/14)
Transmission type:
Constant mesh 5-speed
Operation:
Left foot operation
Gear ratio:
1st:
3.181 (35/11)
2nd:
1.875 (30/16)
3rd:
1.250 (25/20)
4th:
0.875 (21/24)
5th:
0.666 (18/27)
Chassis:
Frame type:
Semi double cradle
Caster angle:
29.50 
Trail:
120 mm (4.7 in)
Front tire:
Type:
With tube
Size:
2.75-19 4PR
