EBU22403
Periodic maintenance and lubrication chart
NOTE:
●
For ATVs not equipped with an odometer or an hour meter, follow the month maintenance intervals.
●
For ATVs equipped with an odometer or an hour meter, follow the km (mi) or hours maintenance inter-
vals. However, keep in mind that if the ATV isn’t used for a long period of time, the month maintenance
intervals should be followed.
●
Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools,
data and technical skills.
NO. ITEM
CHECK OR MAINTENANCE
JOB
INITIAL EVERY
Whichev-
er comes
first
month 1 3 6 6 12
km
(mi)
320
(200)
1200
(750)
2400
(1500)
2400
(1500)
4800
(3000)
hours 20 75 150 150 300
1
*
Fuel line
●
Check fuel hoses for cracks or other damage, and
replace if necessary.
√√√
2 Spark plug
●
Replace.
√√√√√
3 Air filter element
●
Clean and replace if necessary.
Every 20–40 hours (more often in wet or
dusty areas)
4
*
Clutch
●
Check operation and adjust if necessary.
√ √√√
5
*
Front brake
●
Check operation and correct if necessary.
●
Check fluid level and ATV for fluid leakage, and
correct if necessary.
√√√√√
●
Replace brake pads. Whenever worn to the limit
To Next Page
