EBU23360
Autolube pump
The Autolube pump is a vital part of the engine and
requires very sophisticated adjustment. The Autol-
ube pump should be checked and, if necessary,
adjusted at the intervals specified in the periodic
maintenance and lubrication chart. Any adjusting
should be left to a Yamaha dealer who has the pro-
fessional knowledge and experience to do so.
EBU23781
Cleaning the air filter element
The air filter element should be cleaned at the in-
tervals specified in the periodic maintenance and
lubrication chart. Clean the air filter element more
frequently if you are riding in unusually wet or dusty
areas.
NOTE:
There is a check hose at the bottom of the air filter
case. If dust or water collects in this hose, empty
the hose and clean the air filter element and air fil-
ter case.
1. Remove the seat. (See page 4-11.)
2. Remove the air filter case cover by removing
the screws.
1. Air filter case check hose
1
