Shock absorber
assemblies
●
Check operation and correct if necessary.
●
Check for oil leakage and replace if necessary.
√√√
17
*
Steering shaft
●
Lubricate with lithium-soap-based grease.
√√√
18
*
Steering system
●
Check operation and repair or replace if damaged.
●
Check toe-in and adjust if necessary.
√√√√√
19
*
Carburetor
●
Check starter (choke) operation and correct if nec-
essary.
●
Check engine idling speed and adjust if neces-
sary.
√√√√
20
*
Crankcase breather
system
●
Check breather hose for cracks or other damage,
and replace if necessary.
√√√
21 Transmission oil
●
Change.
●
Check ATV for oil leakage, and correct if neces-
sary.
√ √√√
22
*
Autolube pump
●
Check operation and bleed if necessary.
√√√
23
*
Moving parts and
cables
●
Lubricate.
√√√√
24
*
Throttle lever hous-
ing and cable
●
Check operation and correct if necessary.
●
Check throttle cable free play and adjust if neces-
sary.
●
Lubricate throttle lever housing and cable.
√√√√√
25
*
Exhaust system
●
Check for leakage and replace gasket(s) if neces-
sary.
●
Check for looseness and tighten all screw clamps
and joints if necessary.
√√√
NO. ITEM
CHECK OR MAINTENANCE
JOB
INITIAL EVERY
Whichev-
er comes
first
month 1 3 6 6 12
km
(mi)
320
(200)
1200
(750)
2400
(1500)
2400
(1500)
4800
(3000)
hours 20 75 150 150 300
To Next Page
