19
CD-1330
CD-1330
5.[Refer...]をクリックし、書き込むファームウェア
を選択します。(Fig.6)
ID、および MCUType は書き込みファイル選
択時、自動的に取り込まれます。(Fig.6)
[OK]をクリックします。(Fig.6)
5. Click [Refer...]. And select the firmware name.
(Fig. 6)
* The ID code and MCU type are loaded
automatically when the file is selected. (Fig. 6)
Click [OK]. (Fig. 6)
Fig. 6
Click to open the window
ここをクリックすると
ウィンドウが開きます
3. FlashSta.exe を立ち上げます。
すると下記の画面が表示されます。(Fig.5)
3. Start up FlashSta.exe, the screen will appear as
shown below. (Fig. 5)
Select Internal flash memory
Internalflashmemory を選択します
Select the port of RS-232C
接続している RS-232C ポートを選択します
Fig. 5
4. 送信データ、ポートを選択します。(Fig.5)
SelectProgram
Internalflashmemory を選択します。
RS232C
接続している RS-232C ポートを選択します。
※ ポートの選択は COM1 4 までが使用できま
す。
COM5 以上は使用できませんので、PC 側の設
定で COM1 4 を選択してください。
4. Select the port and data to be transmitted. (Fig. 5)
• Select Program
Select Internal flash memory
• RS232C
Select the port of RS-232C
* For selection of the port, COM1 to 4 can be
used.
As COM5 or higher port cannot be used, se-
lect out of COM 1 to 4 of the setting on the PC
side.
