18 En
Connections
SYSTEM CONNECTOR
REMOTE
IN OUT
BALANCED OUT DIGITAL IN
COAXIALOPTICALUSB
ANALOG OUT BALANCED OUT
GND +HOT
- COLD
2
3
1
AC IN
If your amplifier is equipped with XLR
balanced input jacks,
we recommend balanced connection
for optimum audio performance.
When the SA-CD layer is played, the
audio signals are output only from the
BALANCED OUT and ANALOG OUT
jacks.
XLR balanced cable
Stereo pin cable
Amplifier
To Next Page
