Yamaha CDC-697 - Power Connection and Voltage Settings; Connecting the AC Power Cable; Adjusting the Voltage Selector

5 En
GETTING STARTED
English
Connecting the power cable
After all other connections are completed, plug the power cable to an AC wall outlet.
■ VOLTAGE SELECTOR (Asia and General models only)
The VOLTAGE SELECTOR on the rear panel of this unit must be set for your local main voltage BEFORE plugging into the
AC main supply. Voltages are AC 110/120/220/230–240 V, 50/60 Hz.
AC IN
• China, Asia and General models
• Other models
Plug the power cable into the AC IN, then plug the power
cable to an AC wall outlet.
To AC wall outlet
To AC wall outlet
VOLTAGE SELECTOR
230-
240V
PREPARATIONS
