% : Note on the Main PCB
Of the main PCB part Nos., only the silver (SI) type part Nos. are included in the table.
The only different part between the gold (GD) and silver (SI) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a GD type main PCB becomes necessary, order a SI type main PCB and a
GD type sheet/FL (VQ948800) and replace the sheet/FL of the SI type main PCB with the GD type sheet/FL.
Schm
Ref. PART NO. Description
New Parts
*
Schm
Ref. PART NO. Description
New Parts
*
% V4220700 P.C.B. SI:MAIN(UC)
% V4220800 P.C.B. SI:MAIN(R)
% V4220900 P.C.B. SI:MAIN(A)
% V4221000 P.C.B. SI:MAIN(B)
% V4221100 P.C.B. SI:MAIN(G)
CB1 V2731000 CN.FMN 16P
CB2 VB390200 CN.BS.PIN 6P
CB3 VB390100 CN.BS.PIN 5P
* CB4 VQ964000 CN.BS.PIN 19P
* CB5 VQ962200 CN.BS.PIN 19P
* CB6 VN394900 CN.BS.PIN 14P
CB8 VQ962300 CN.BS.PIN 20P
CB9 VQ964100 CN.BS.PIN 20P
CB10 VG879900 CN.BS.PIN 2P
CB12 VT707200 L.EMIT TOTX178
CB13 VB390100 CN.BS.PIN 5P
CB17 VF982200 CN.BS.PIN 14P
CB18 VP206500 HOLDER.FUS EYF-52BC(G)
CB19 VP206500 HOLDER.FUS EYF-52BC(G)
C1 UR818100 C.EL 100uF 6.3V
C2 UB045100 C.CE.M.CHP 0.1uF 50V
C3 UA953330 C.MYLAR 3300pF 50V
C4 UR818100 C.EL 100uF 6.3V
C5 UR818100 C.EL 100uF 6.3V
C6 UR818100 C.EL 100uF 6.3V
C7 UB044100 C.CE.M.CHP 0.01uF 50V
C8 UR847470 C.EL 47uF 25V
C9 UR837470 C.EL 47uF 16V
C10 UB013100 C.CE.M.CHP 1000pF 50V
C11 UB051100 C.CE.M.CHP 10pF 50V
C12 VR498100 C.EL 6.8uF 6.3V
C13 UR818100 C.EL 100uF 6.3V
C14 UB045100 C.CE.M.CHP 0.1uF 50V
C15 UA655220 C.MYLAR 0.22uF 50V
C16 UR818100 C.EL 100uF 6.3V
C17 UA655100 C.MYLAR 0.1uF 50V
C18 UA655100 C.MYLAR 0.1uF 50V
C19 UA954470 C.MYLAR 0.047uF 50V
C20 UA953180 C.MYLAR 1800pF 50V
C21 UA953120 C.MYLAR 1200pF 50V
C22 UA655100 C.MYLAR 0.1uF 50V
C23 UA953470 C.MYLAR 4700pF 50V
C24 UA655100 C.MYLAR 0.1uF 50V
C25 UA952100 C.MYLAR 100pF 50V
C26 UA953220 C.MYLAR 2200pF 50V
C27 UA953220 C.MYLAR 2200pF 50V
C28 UR866100 C.EL 1uF 50V
C29 UA655100 C.MYLAR 0.1uF 50V
C30 UB012270 C.CE.M.CHP 270pF 50V
C31 UA655270 C.MYLAR 0.27uF 50V
C32 UB045100 C.CE.M.CHP 0.1uF 50V
C33 UN865470 C.EL 0.47uF 50V
C34 UA954680 C.MYLAR 0.068uF 50V
C35 UB045100 C.CE.M.CHP 0.1uF 50V
C36 UB045100 C.CE.M.CHP 0.1uF 50V
* C37 VJ901100 C.CE.M.CHP 47pF 50V
* C38 VJ901100 C.CE.M.CHP 47pF 50V
* C39 VG290600 C.EL 2.2uF 50V
* C40 VG290600 C.EL 2.2uF 50V
* C41 VG290600 C.EL 2.2uF 50V
* C42 VG290600 C.EL 2.2uF 50V
C43 UB045100 C.CE.M.CHP 0.1uF 50V
C44 VG286500 C.EL 470uF 10V
C45 UB045100 C.CE.M.CHP 0.1uF 50V
C46 UB045100 C.CE.M.CHP 0.1uF 50V
C47 UR818100 C.EL 100uF 6.3V
C48 UB045100 C.CE.M.CHP 0.1uF 50V
C49 UJ818100 C.EL 100uF 10V
C50 UB044100 C.CE.M.CHP 0.01uF 50V
C51 UA952560 C.MYLAR 560pF 50V
C52 UA952560 C.MYLAR 560pF 50V
C54 UR818100 C.EL 100uF 6.3V
C55 UR865680 C.EL 0.68uF 50V
C56 UB045100 C.CE.M.CHP 0.1uF 50V
C57 UR818100 C.EL 100uF 6.3V
C58 UR837100 C.EL 10uF 16V
C59 UR837470 C.EL 47uF 16V
C60 UR828100 C.EL 100uF 10V
C61 UR866470 C.EL 4.7uF 50V
C62 UR868100 C.EL 100uF 50V
C63 UR866470 C.EL 4.7uF 50V
C64 UR866470 C.EL 4.7uF 50V
C65 UR866470 C.EL 4.7uF 50V
C66 VS741700 C.CE.SAFTY 0.01uF 275V
C67 UA954180 C.MYLAR 0.018uF 50V
C68 UA952120 C.MYLAR 120pF 50V
C69 VG287300 C.EL 22uF 50V
C70 UA953330 C.MYLAR 3300pF 50V
C71 UA953330 C.MYLAR 3300pF 50V
C72 VG287300 C.EL 22uF 50V
C73 UA954180 C.MYLAR 0.018uF 50V
C74 UA952120 C.MYLAR 120pF 50V
C77 UR848220 C.EL 220uF 25V
Z C78 FG644100 C.CE 0.01uF 50V
C79 VG287900 C.EL 470uF 16V
Z C80 FG644100 C.CE 0.01uF 50V
C81 Vi578400 C.EL 6800uF 16V
C82 UR867470 C.EL 47uF 50V
C83 FG644100 C.CE 0.01uF 50V
C84 UA953220 C.MYLAR 2200pF 50V
C85 UA953220 C.MYLAR 2200pF 50V
C86 UB045100 C.CE.M.CHP 0.1uF 50V
C87 UB045100 C.CE.M.CHP 0.1uF 50V
C88 UB044100 C.CE.M.CHP 0.01uF 50V
C100 UB051240 C.CE.M.CHP 24pF 50V
C101 UB045100 C.CE.M.CHP 0.1uF 50V
C102 UB045100 C.CE.M.CHP 0.1uF 50V
C103 UR837470 C.EL 47uF 16V
C104 UB052100 C.CE.M.CHP 100pF 50V
C105 UA952220 C.MYLAR 220pF 50V
C106 UA952220 C.MYLAR 220pF 50V
* D1 VU991900 DIODE.ZENR MA8043-H 4.4V
D2 VT332900 DIODE 1SS355
D4 VT332900 DIODE 1SS355
D5 VT332900 DIODE 1SS355
D6 VT332900 DIODE 1SS355
* D7 VU992600 DIODE.ZENR MA8051-M 5.1V
D8 VU993000 DIODE.ZENR MA8056-M 5.6V
Z D9 VU264200 DIODE 1SR139-400
D10 VU993000 DIODE.ZENR MA8056-M 5.6V
* D11 VU999400 DIODE.ZENR MA8270-L 26V
Z D15 VU264200 DIODE 1SR139-400
Z D16 VU264200 DIODE 1SR139-400
Z D17 VU264200 DIODE 1SR139-400
