Yamaha CDX-E100 - Exploded View

■ EXPLODED VIEW
32
ABCDE
1
2
3
4
5
6
7
CDX-E100
% : Note on the Main PCB
Of the main PCB part Nos., only the silver (SI) type part Nos. are included in the table.
The only different part between the gold (GD) and silver (SI) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a GD type main PCB becomes necessary, order a SI type main PCB and a
GD type sheet/FL (VQ948800) and replace the sheet/FL of the SI type main PCB with the GD type sheet/FL.
