■ MECHANICAL PARTS
% : Note on the Main PCB
Of the main PCB part Nos., only the gold (GD) type part Nos. are included in the table. (G, B models)
The only different part between the silver (SI) and gold (GD) type parts is the sheet/FL that is attached to the
fluorescent character display tube. When a SI type main PCB becomes necessary, order a GD type main PCB and a
SI type sheet/FL (V3688400) and replace the sheet/FL of the GD type main PCB with the SI type sheet/FL.
Ref.
No. PART NO. Description Remarks Markets
New Parts
*
1‑11 MF114100 FLEXIBLEFLATCABLE 14P100mm
* 1‑101 V8782200 FRONTPANEL SI
* 1‑101 V8782300 FRONTPANEL GD
* 1‑102 V8782400 SUBPANEL‑CDX SI
* 1‑102 V8782500 SUBPANEL‑CDX GD
* 1‑103 V8785200 PANEL/SIDE H100
* 1‑104 V8782600 SHEET
1‑110 VQ368600 PUSHRIVET P3555‑B
1‑111 VF617600 PANHEADP‑TITESCREW 2.6x8MFC2BL
* 2 V9356200 P.C.B.ASS'Y GD:MAIN R
* 2 V9356300 P.C.B.ASS'Y GD:MAIN GB
5 VZ573200 CDMECHANISMUNIT KSL‑2130CCM
Z 11 VZ542500 POWERCABLE 2m R
Z * 11 V9293600 POWERCABLE 2m G
Z 11 VV437300 POWERCABLE 2m B
12 V2438700 CORDSTOPPER 10P1
* 15 V8835000 SUMI‑CARDC&C 16P100mmP=1.00
101 V7127300 TOPCOVER SI
101 V7127400 TOPCOVER GD
* 103 V8783000 REARPANEL R
* 103 V8783200 REARPANEL G
* 103 V8783100 REARPANEL B
* 106 V8782700 LID,CD SI
* 106 V8782800 LID,CD GD
110 V3688500 LEG M0080‑M0
120 VR264400 SPACER H8
121 VQ390100 DAMPER 8x8x15
122 VP857700 DAMPER 4x6x5
140 VN413300 BINDHEADBONDINGB‑T.SCREW 3x8MFZN2BL
142 EP600830 BINDHEADB‑TITESCREW 3x8MFC2BL
143 EP600250 BINDHEADB‑TITESCREW 3x8MFZN2Y
144 VT669300 PWHEADB‑TITESCREW 3x8‑8MFC2
145 VT669400 PWHEADB‑TITESCREW 3x15‑8MFC2
146 V2728500 BINDHEADS‑TITESCREW 4x7MFZN2BL
148 EL300650 PWHEADB‑TITESCREW 3x8‑8MFC2BL
149 EP600790 FLATHEADB‑TITESCREW 3x8MFZN2BL
150 VY712800 PWHEADB‑TITESCREW 3x8‑8MFNI33
151 EP630210 BINDHEADS‑TITESCREW 3x6MFZN2BL
152 EG330030 BINDHEADSCREW 3x6MFC2BL R
% V3688400 SHEET,FL SI SI
