Controls and functions
Top panel
The top panel of the CL series is divided into the following sections.
1 Channel Strip section ➔ page 11
2 SELECTED CHANNEL section ➔ page 12
3 Display section ➔ page 13
4 Centralogic section ➔ page 13
5 SCENE MEMORY/MONITOR section ➔ page 14
6 USER DEFINED KNOBS section ➔ page 14
7 USER DEFINED KEYS section ➔ page 14
8 Master section ➔ page 15
9 USB connector ➔ page 15
0 Meter section (for CL5 only) ➔ page 15
NOTE
This illustration shows the top panel of the CL5.
The CL3 and CL1 do not feature a Meter section, but enable you to install an optional MBCL meter bridge.
