Yamaha CL3 - Pin Assignment

Pin Assignment
Owner’s Manual
57
Pin Assignment
DC POWER INPUT GPI
METER (CL3/CL1 only)
Pin Signal Name Pin Signal Name
1+24V13GND
2+24V14GND
3+24V15GND
4+24V16GND
5+24V17GND
6+24V18GND
7 +24V 19 CAUTION(+)
8 +24V 20 CAUTION(–)
9 +24V 21 DETECT A
10 GND 22 DETECT B
11 GND 23 DETECT GND
12 GND Frame GND
1
2
3
4
5
6789
10111213
14
15
16
17181920
21
22
23
Pin Signal Name Pin Signal Name
1GPO19GPO2
2 GPO310GPO4
3GPO511GND
4GND12GND
5 +5V 13 +5V
6 GPI1 14 GPI2
7 GPI3 15 GPI4
8GPI5
Pin Signal Name Pin Signal Name
1RESET6+3.3LD
2SDA7+3.3LD
3 DGND 8 LDGND
4SCL9LDGND
5 +3.3D
91011
8
123
15
1
6
5
9
