Input/output characteristics
ANALOG INPUT CHARACTERISTICS
*1. Sensitivity is the lowest level that will produce an output of +4dBu (1.23V) or the nominal output level when the unit is set to maximum
gain. (all faders and level controls are maximum position.)
*2. XLR-3-31 type connectors are balanced. (1= GND, 2= HOT, 3= COLD)
*3. In these specifications, 0dBu= 0.775 Vrms.
*4. All input AD converters are 24bit linear, 128times oversampling.
*5. +48V DC ( phantom power ) is supplied to OMNI IN (1-8) and TALKBACK XLR type connectors via each individual software controlled
switches.
ANALOG OUTPUT CHARACTERISTICS
*1. XLR-3-32 type connectors are balanced. (1= GND, 2= HOT, 3= COLD)
*2. PHONES stereo phone jack is unbalanced. (Tip= LEFT, Ring= RIGHT, Sleeve= GND)
*3. In these specifications, 0dBu= 0.775 Vrms.
*4. All output DA converters are 24bit, 128times oversampling.
*5. There are switches inside the body to preset the maximum output level.
*6. The position of the level control is 10dB lowered from Max.
DIGITAL INPUT & OUTPUT CHARACTERISTICS
DIGITAL OUTPUT CHARACTERISTICS
*1. XLR-3-32 type connectors are balanced. (1= GND, 2= HOT, 3= COLD)
I/O SLOT (1-3) CHARACTERISTICS
Each I/O Slot accepts a mini-YGDAI card. Only Slot1 has a serial interface.
CONTROL I/O CHARACTERISTICS
*1. Input pin: TTL level, w/ internal pull-up (47kΩ)
Output pin: Open drain output (Vmax=12V, maximum sink current/pin=75mA)
Power supply pin: Output voltage Vp=5V, Max. output current Imax=300mA
*2. 4pin= +12V, 3pin= GND, Lamp rating 5W. Voltage control by software.
Input
Terminals
GAIN
Actual Load
Impedance
For Use With
Nominal
Input Level
Connector
Sensitivity
*1
Nominal Max. before clip
OMNI IN 1-8
+66dB
10kΩ
50-600Ω Mics
& 600Ω Lines
–82dBu (61.6μV) –62dBu (0.616mV) –42dBu (6.16mV)
XLR-3-31 type
(Balanced)
*2
+18dB –34dBu (15.5mV) –14dBu (155mV) +6dBu (1.55V)
+17dB
3kΩ
–33dBu (17.4mV) –13dBu (174mV) +7dBu (1.74V)
–6dB –10dBu (245mV) +10dBu (2.45V) +30dBu (24.5V)
TALKBACK
+64dB
10kΩ
50-600Ω Mics
& 600Ω Lines
–70dBu (0.245mV) –60dBu (0.775mV) –40dBu (7.75mV) XLR-3-31 type
(Balanced)
*2
+20dB –26dBu (38.8mV) –16dBu (0.123V) +4dBu (1.23V)
Output
Terminals
Actual Source
Impedance
For Use With
Nominal
GAIN SW
*5
Output Level
Connector
Nominal Max. before clip
OMNI OUT 1-8 75Ω 600Ω Lines
+24dB (default) +4dBu (1.23V) +24dBu (12.3V) XLR-3-32 type
(Balanced)
*1
+18dB –2dBu (616mV) +18dBu (6.16V)
PHONES 15Ω
8Ω Phones
75mW
*6
150mW
Stereo Phone Jack (TRS)
(Unbalanced)
*2
40Ω Phones
65mW
*6
150mW
Terminal Format Data length Level Audio Connector
Primary/Secondary Dante 24bit or 32bit 1000Base-T 64ch Input/64ch Output @48kHz EtherCON Cat5e
Terminal Format Data Length Level Connector
DIGITAL OUT AES/EBU AES/EBU Professional Use 24bit RS422
XLR-3-32 type (Balanced)
*1
Terminal Format Level Connector
MIDI
IN MIDI DIN Connector 5P
OUT MIDI DIN Connector 5P
WORD CLOCK
IN TTL/75Ω terminated BNC Connector
OUT TTL/75Ω BNC Connector
GPI (5IN/5OUT)
D Sub Connector 15P (Female)
*1
NETWORK IEEE802.3 10BASE-T/100Base-TX RJ-45
LAMP (CL5: x3, CL3: x2, CL1: x1)
0V-12V
*4
XLR-4-31 type
*2
USB HOST USB 2.0 USB A Connector (Female)
DC POWER INPUT JL05 Connector
METER (CL3/CL1 only) D Sub Connector 9P (Female)
