Component side
CN601:
CN602:
CN603:
CN604:
CN605:
to AC 1/6-W601
to AC 1/6-W602
to AC 1/6-W603
to AC cord (L)
to AC cord (N)
CN606:
CN607:
CN608:
CN609:
CN610:
to Power transformer
to Power transformer
to Power transformer
to Power transformer
to Power transformer
CN611:
CN612:
W604:
W605:
W606:
to Power transformer
to AC 3/6-W608
to PA-CN102
to PA-CN103
to PA-CN104
to IN-CN301
to Power
transformer
U, V, T
H, W, B
A
BL
CN604
BR
BR
WH
CN605
BE
BE
BR
CN606, CN607
BE
RE
• Wire Colors
CP2000
16
AC 2/6 Circuit Board
3NA-V607220
