Yamaha CRX-E500 - Page 42

CDC-E500
43
Schm
Ref. PART NO. Description
Markets
✻ New Parts
Chip Resistors
Schm
Ref. PART NO. Description Markets
✻ New Parts
RD350000 R.CAR.CHP 0Ω1/10W
RD354100 R.CAR.CHP 10Ω1/10W
RD354470 R.CAR.CHP 47Ω1/10W
RD355240 R.CAR.CHP 240Ω1/10W
RD355330 R.CAR.CHP 330Ω1/10W
RD355390 R.CAR.CHP 390Ω1/10W
RD355470 R.CAR.CHP 470Ω1/10W
RD355560 R.CAR.CHP 560Ω1/10W
RD355680 R.CAR.CHP 680Ω1/10W
RD355820 R.CAR.CHP 820Ω1/10W
RD356100 R.CAR.CHP 1KΩ1/10W
RD356120 R.CAR.CHP 1.2KΩ1/10W
RD356270 R.CAR.CHP 2.7KΩ1/10W
RD356300 R.CAR.CHP 3KΩ1/10W
RD356330 R.CAR.CHP 3.3KΩ1/10W
RD356390 R.CAR.CHP 3.9KΩ1/10W
RD356470 R.CAR.CHP 4.7KΩ1/10W
RD356510 R.CAR.CHP 5.1KΩ1/10W
RD356750 R.CAR.CHP 7.5KΩ1/10W
RD356820 R.CAR.CHP 8.2KΩ1/10W
RD356910 R.CAR.CHP 9.1KΩ1/10W
RD357100 R.CAR.CHP 10KΩ1/10W
RD357120 R.CAR.CHP 12KΩ1/10W
RD357220 R.CAR.CHP 22KΩ1/10W
RD357270 R.CAR.CHP 27KΩ1/10W
RD357300 R.CAR.CHP 30KΩ1/10W
RD357330 R.CAR.CHP 33KΩ1/10W
RD357390 R.CAR.CHP 39KΩ1/10W
RD357470 R.CAR.CHP 47KΩ1/10W
RD358100 R.CAR.CHP 100KΩ1/10W
RD358150 R.CAR.CHP 150KΩ1/10W
RD358160 R.CAR.CHP 160KΩ1/10W
RD358180 R.CAR.CHP 180KΩ1/10W
RD358220 R.CAR.CHP 220KΩ1/10W
RD358270 R.CAR.CHP 270KΩ1/16W
RD358330 R.CAR.CHP 330KΩ1/10W
RD359100 R.CAR.CHP 1MΩ1/10W
RD359150 R.CAR.CHP 1.5MΩ1/10W
RF457470 R.CAR.CHP 47KΩ1/10W
C300 US135100 C.CE.CHP 0.1uF16V
C301 US135100 C.CE.CHP 0.1uF16V
C302 US061240 C.CE.CHP 24pF50V
C303 US062100 C.CE.M.CHP 100pF50V
C500 V6185300 C.CE.SAFTY 0.01uF275V
D1 VU993000 DIODE.ZENR MA8056‑M5.6V
D2 VU993500 DIODE.ZENR MA8062‑H6.4V
D3 VU993000 DIODE.ZENR MA8056‑M5.6V
D4 VT332900 DIODE 1SS355
D5 VT332900 DIODE 1SS355
D6 VU999500 DIODE.ZENR MA8270‑M27V
D7 VU993400 DIODE.ZENR MA8062‑M6.2V
D8 VU992600 DIODE.ZENR MA8051‑M5.1V
s D9 VV307700 DIODE 1N4002S
s D10 VV307700 DIODE 1N4002S
s D11 VV307700 DIODE 1N4002S
s D14 VV307700 DIODE 1N4002S
s D15 VV307700 DIODE 1N4002S
s D18 VV307700 DIODE 1N4002S
s D19 VV307700 DIODE 1N4002S
s D20 V4269600 DIODE.BRG
D2SBA201.5A200V
D200 VT332900 DIODE 1SS355
D201 VT332900 DIODE 1SS355
D202 VT332900 DIODE 1SS355
D203 VT332900 DIODE 1SS355
D204 VT332900 DIODE 1SS355
D205 VT332900 DIODE 1SS355
D206 VT332900 DIODE 1SS355
IC1 X0070A00 IC AN4801SB‑E1
IC2 XR274A00 IC TA8409SE
IC3 XR274A00 IC TA8409SE
IC5 XJ604A00 IC NJM78M05FA
IC6 XP157A00 IC M51953BFP
IC200 X0071A00 IC AN8399SA‑E1
* IC201 X3103A00 IC
M30622M8A‑5M4FP
IC202 XW915A00 IC MN35511AL
IC203 XV953A00 IC S‑29190AFJAEEPROM
IC207 X3505A00 IC NJM2068MD‑TE2
IC208 X3505A00 IC NJM2068MD‑TE2
IC300 XR188A00 IC LC75710NEFLD
JK1 V3576300 JACK 2P
L1 VP133800 FER.BEAD BL02RN1‑R62T4
L2 VP133800 FER.BEAD BL02RN1‑R62T4
L200 VD473700 COIL 60uH
L201 VP133800 FER.BEAD BL02RN1‑R62T4
s L500 VU984000 FLTR IE‑UU10.5‑009
L501 Vi491100 FER.CORE
BP53RB19012080M
PJ1 V4925100 JACK.PIN 2P
PN1 V8637500 PIN L=50#18
PN2 V8637500 PIN L=50#18
PN3 V8637500 PIN L=50#18
Q1 iB054430 TR 2SB544D,E,F,G
Q2 VZ725900 TR 2SD1938FS,T
Q3 iA093320 TR 2SA933SQ,R
Q4 VR510800 TR 2SD2396J,K
Q5 iA093320 TR 2SA933SQ,R
Q6 VZ725900 TR 2SD1938FS,T
Q7 VZ725900 TR 2SD1938FS,T
Q8 VZ725900 TR 2SD1938FS,T
Q9 VZ725900 TR 2SD1938FS,T
R8 HV753220 R.CAR.FP 2.2Ω1/4W
R17 HV755100 R.CAR.FP 100Ω1/4W
R19 HV755100 R.CAR.FP 100Ω1/4W
Schm
Ref. PART NO. Description
Markets
✻ New Parts
P.C.B. MAIN
Schm
Ref. PART NO. Description Markets
✻ New Parts
R23 HV756220 R.CAR.FP 2.2KΩ1/4W
R27 Vi868300 R.FUS 0.68Ω1/6W
R28 HV755390 R.CAR.FP 390Ω1/4W
R50 HV753330 R.CAR.FP 3.3Ω1/4W
R51 HV754100 R.CAR.FP 10Ω1/4W
R257 HV755100 R.CAR.FP 100Ω1/4W
R258 HV755100 R.CAR.FP 100Ω1/4W
R268 HV755100 R.CAR.FP 100Ω1/4W
R269 HV755100 R.CAR.FP 100Ω1/4W
ST2 V4040500 SCR.TERM M3
ST3 V4040500 SCR.TERM M3
SW300 VV020300 SW.TACT SKQNAA
SW301 VV020300 SW.TACT SKQNAA
SW302 VV020300 SW.TACT SKQNAA
SW303 VV020300 SW.TACT SKQNAA
SW304 VV020300 SW.TACT SKQNAA
SW305 VV020300 SW.TACT SKQNAA
SW306 VV020300 SW.TACT SKQNAA
SW307 VV020300 SW.TACT SKQNAA
SW308 VV020300 SW.TACT SKQNAA
s T500 X0138A00 TRANS.PWR UC
s T500 X0140A00 TRANS.PWR A
TP200 VT969000 PIN.TEST IRS‑2049
TP201 VT969000 PIN.TEST IRS‑2049
V300 V6951300 FL.DSPLY 14‑BT‑66GN
XL200 VJ719800 RSNR.CRYS 16.9344MHz
* XL201 V8222200 RSNR.CE
CSTLS10M0G53‑A0
V3747500 SUPRT
V3747400 SPACER.FL T4x6x18
VQ948800 SHEET.FL GD
! V3688400 SHEET.FL SI
