3
DBR10/DBR12/DBR15
SPECIFICATIONS（総合仕様）
General DBR15 DBR12 DBR10
System Type 2-way, Bi-amp Powered Speaker, Bass-refl ex Type
Frequency Range (-10dB) 50Hz–20kHz 52Hz–20kHz 55Hz–20kHz
Coverage Angle H90° x V60° Constant Directivity Horn
Crossover Type FIR-X Tuning (Linear Phase FIR Filter)
Crossover Frequency 2.1kHz 2.1kHz 2.1kHz
Measured Maximum SPL (peak)
IEC noise@1m
132dB SPL 131dB SPL 129dB SPL
Transducer DBR15 DBR12 DBR10
LF Diameter 15" Cone 12" Cone 10" Cone
Voice coil 2.5" 2" 2"
Magnet Ferrite
HF Diaphragm 1.4" 1"
Type 1" Throat Compression Driver
Magnet Ferrite
Enclosure DBR15 DBR12 DBR10
Material, Color Plastic, Black
Floor Monitor Angle 50° Symmetrical 50° Symmetrical 50°
Dimensions
(WxHxD, with rubber feet)
455 x 700 x 378 mm
(17.9" x 27.6" x 14.9")
376 x 601 x 348 mm
(14.8" x 23.7" x 13.7")
308 x 493 x 289 mm
(12.1" x 19.4" x 11.4")
Net Weight 19.3kg (42.6lbs) 15.8kg (34.8lbs) 10.5kg (23.2lbs)
Handles Side x 2 Top x 1
Pole Socket 35mm
Rigging points Bottom x 2, Rear x 1 (Fit for M8 x 15mm Eyebolts) Bottom x 2 (Fit for M8 x 15mm
Eyebolts)
Optional Seaker Bracket BBS251, BCS251, BWS251-300, BWS251-400
Amplifi er DBR15 DBR12 DBR10
Amplifi er Type Class-D
Power Rating
*1
Dynamic 1000W (LF: 800W, HF: 200W) 700W (LF: 500W, HF: 200W)
Continuous 465W (LF: 400W, HF: 65W) 325W (LF: 260W, HF: 65W)
Cooling Fan cooling, 4 speeds
AD/DA 24bit 48kHz sampling
HPF/LPF OFF, 100Hz, 120Hz, 24dB/Oct. HPF
DSP preset D-CONTOUR: FOH/MAIN, MONITOR, OFF
Protection Speaker Clip Limiting, Integral Power Protection, DC-fault
Amplifi er Thermal, Output Over Current
Power supply Thermal, Output Over Voltage, Output Over Current
Connectors Input Input1: Combo x1, Input2: Combo x1, RCA PIN x2 (Unbalanced)
Output Output: XLR3-32 x1 (CH1 Parallel Through or CH1+CH2 Mix)
Input Impedance INPUT1 (XLR, Phone): 3 k
Ω
, INPUT2 (XLR, Phone, RCA Pin): 10 k
Ω
Input Sensitivity (LEVEL: Maximum) INPUT1: LINE: 0 dBu, MIC: -32 dBu, INPUT2: 0 dBu
Input Sensitivity (LEVEL: Center) INPUT1: LINE: +10 dBu, MIC: -22 dBu, INPUT2: +10 dBu
Maximum Input Level INPUT1: LINE: +24 dBu, MIC: -8 dBu, INPUT2: +24 dBu
Controls LEVEL x2, LINE/MIC, HPF, D-CONTOUR, THRU/MIX, POWER
Idle Power Consumption 18W
1/8 Power Consumption 74W 60W
Power Requirements 100V, 110–120V, 220–240V, 110/127/220V (Brazil), 50/60Hz
0dBu is referenced to 0.775Vrms.
*1 Power rating (120V, 25°C). This is total value of individual output power.
• Included Accessories
· AC power cord
· Owner's manual
·Technical Specifi cations (English only)
•付属品
·電源コード
·取扱説明書
·スペックシート（英語のみ）
