32
DBR10/DBR12/DBR15
3-2. DSP inspection
Communication condition with DSP via I2C-BUS,
operational state of inside DSP and connection of a DSP-
IRQ terminal are inspected automatically.
The result is displayed in output window as shown below.
When Normal
I2C DSP COM PASS: DSP I2C-COM
I2C DSP CTRL PASS: DSP I2C-CTRL
DSP-IRQ PASS: DSP DSP-IRQ
When out of order
I2C DSP COM FAIL: DSP I2C-COM
I2C DSP CTRL FAIL: DSP I2C-CTRL
DSP-IRQ FAIL: DSP DSP-IRQ
Troubleshooting
If you fail, check wire connection and the following parts.
CPU (PCB DSP : IC504-32pin):DSP-SDA DSP (PCB
DSP : IC402)
CPU (PCB DSP : IC504-33pin):DSP-SCL DSP (PCB
DSP : IC402)
CPU (PCB DSP : IC504-34pin):/DSP-IRQ DSP (PCB
DSP : IC402)
CPU (PCB DSP : IC504-35pin):/DSP-RES DSP (PCB
DSP : IC402)
3-3. AD input port inspection
The voltage (temperature) from T-SENSE port is
inspected automatically.
The result is displayed in output window as shown below.
When Normal
0.52V~1.15V PASS: Temperature *(xxxx mV)
When Abnormal
0.52V or below FAIL: Temperature *( xxxx mV)
1.15 V or above FAIL: Temperature *( xxxx mV)
*( xxxx mV) represents electric pressure measured.
Troubleshooting
If you fail, check wire connection and the following parts.
CPU(PCBDSP:IC504:8pin):T-SENSE →CN504 →
AMPMODULE(AMPS)
3-2. DSP 検査
I2C-BUS経由 DSP との通信状態の良否、DSP
部の動作状態の良否、DSP-IRQ端子の接続を自動的
に検査します。
検査結果はアウトプットウインドウへ下記のように
表示されます。
正常時
I2CDSPCOM PASS:DSPI2C-COM
I2CDSPCTRL PASS:DSPI2C-CTRL
DSP-IRQ PASS:DSPDSP-IRQ
故障時
I2CDSPCOM FAIL:DSPI2C-COM
I2CDSPCTRL FAIL:DSPI2C-CTRL
DSP-IRQ FAIL:DSPDSP-IRQ
トラブルシューティング
失敗した場合、次の部品及び結線を確認します。
CPU(PCBDSP:IC504-32pin):DSP-SDA→DSP(PCB
DSP:IC402)
CPU(PCBDSP:IC504-33pin):DSP-SCL→DSP(PCB
DSP:IC402)
CPU(PCBDSP:IC504-34pin):/DSP-IRQ →DSP
(PCBDSP:IC402)
CPU(PCBDSP:IC504-35pin):/DSP-RES →DSP
(PCBDSP:IC402)
3-3. AD入力ポート検査
T-SENSEポートからの電圧(温度)を自動的に検査
します。
検査結果はアウトプットウインドウへ下記のように
表示されます。
正常時
0.52V 1.15V PASS:Temperature*(xxxxmV)
異常時
0.52V以下 FAIL:Temperature*(xxxxmV)
1.15V以上 FAIL:Temperature*(xxxxmV)
*(xxxxmV) は、測定した電圧を表示します。
トラブルシューティング
失敗した場合、次の部品及び結線を確認します。
CPU(PCBDSP:IC504:8pin):T-SENSE →CN504 →
AMPMODULE(AMPS)
