Yamaha DSP-AX2400 User Manual

RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
26
No DIAG menu sub-menu
12 AD DATA CHECK 1. DC/PS (protection)
/FAN TEST 2. THM/FAN OUT
3. REC-OUT
4. IMP SW/POWER LIMIT
5. K0/K1 (panel key)
6. FAN DRIVE TEST: HIGH (Fan test only applies to models with a fan.)
7. FAN DRIVE TEST: MID (Fan test only applies to models with a fan.)
8. FAN DRIVE TEST: LOW (Fan test only applies to models with a fan.)
13 V CONV STATUS 1. LOW BYTE DATA
2. HIGH BYTE DATA (Not applied to these models. / 
14 IF STATUS 1. IS 1 (5 Byte)
2. IS 2 (3 Byte)
3. CS 1 (5 Byte)
4. CS 2 (5 Byte)
5. CS 3 (5 Byte)
6. CS 4 (5 Byte)
7. CS 5 (4 Byte)
8. BS1 (5 Byte)
9. BS2 (5 Byte)
10. BS3 (5 Byte)
11. BS4 (5 Byte)
12. BS5 (5 Byte)
13. TI1 (5 Byte)
14. TI2 (1 Byte)
15. MTT (5 Byte)
15 DSP RAM CHECK 1. YSS930 BUS CHECK
2. SECOND DECODER BUS CHECK
16 PROTECTION SET Not applied to these models. / 
17 SOFT SW 1. SW MODE
2. MODEL SETTING
3. TUNER DESTINATION
4. TUNER EXIST
5. RDS EXIST
6. ZONE 2 EXIST
7. VIDEO FORMAT
18 ROM VERSION/CHECK SUM/ 1. VERSION
PORT 2. SUM ALL/PROGRAM
3. SUM 232C BOOT/MAKER BOOT
4. PORT
5. AAC PORT
