RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
58
No. Name I/O Function
   For external memory, Address 17
   For external memory, Address 19
   For external memory, Address 20
   For external memory area, Enable 0
   For external memory area, Enable 1
   1.2V power supply
   1.2V power supply
   Ground
   3.3V power supply
   For external memory, Byte Enable Control 1
   For external memory, Address 21
   For external memory, Byte Enable Control 0
   For external memory, Data 13
   For external memory, Data 15
   For external memory, Data 14
   3.3V power supply
   Ground
   1.2V power supply
   For external memory, Data 11
   For external memory, Data 12
   For external memory, Data 9
   For external memory, Data 10
   For external memory, Data 6
   For external memory, Data 7
   For external memory, Data 8
   1.2V power supply
   Ground
   3.3V power supply
   For external memory, Data 4
   For external memory, Data 5
   For external memory, Data 3
   For external memory, Data 2
   For external memory, Data 1
   For external memory, Data 0
   1.2V power supply
   Ground
   General purpose I/O0 port 1
   For external memory, Bus request output
   For external memory, Hold request approval to host
   For external memory, Hold request from host
   McASP1 reception LRCLK
   McASP1 reception BCLK
   3.3V power supply
   Ground
   McASP1 transmission/reception data 0
   McASP1 transmission/reception data 1
   McASP1 transmission/reception data 2
   McASP1 transmission/reception data 3
   McASP1 transmission/reception data 4
   Ground
   1.2V power supply
   McASP1 transmission/reception data 5
   McASP1 transmission/reception data 6
   McASP1 transmission/reception data 7
   McASP1 transmission BCLK
   McASP1 MUTE output
   McASP1 transmission LRCLK
   General purpose I/O0 port 0 (SPI ready signal output Active: H)
IC512: D601A002PYP180 (DSP P.C.B)
Decoder
