RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
57
RX-V2400/RX-V2400RDS/DSP-AX2400
RX-V1400/RX-V1400RDS/HTR-5690/DSP-AX1400
No. Name I/O Function
12C0 clock
12C0 data
1.2V power supply
3.3V power supply
Ground
1.2V power supply
3.3V power supply
Ground
Ground
1.2V power supply
1.2V power supply
Ground
1.2V power supply
Ground
3.3v power supply
Asynchronous RAM Ready input
For external memory area, Enable 3
3.3V power supply
Ground
1.2V power supply
For external memory area, Enable 2
For external memory, Address 2
For external memory, Address 3
For external memory, Address 4
3.3V power supply
Ground
1.2v power supply
For external memory, Address 5
For external memory, Address 6
For external memory, Address 7
For external memory, Address 8
3.3V power supply
Ground
For external memory, Address 9
Asynchronous RAM OE / SDRAM RAS / SBS RAM OE
For external memory, Address 10
Clock output for EMIF
Clock input for EMIF
Asynchronous RAM RE / SDRAM CAS / SBSRAM ADS
1.2V power supply
Ground
Half clock output of device Speed
Asynchronous RAM WE / SDRAM WE / SBSRAM WE
3.3V power supply
Ground
For external memory, Address 11
3.3V power supply
Ground
1.2V power supply
For external memory, Address 14
For external memory, Address 13
For external memory, Address 16
For external memory, Address 12
For external memory, Address 15
For external memory, Address 18
1.2V power supply
Ground
3.3V power supply
IC512: D601A002PYP180 (DSP P.C.B)
Decoder
To Next Page
