6F65G11
6-42
9
8
7
6
5
4
3
2
1
Drive shaft and lower case
3. Install the propeller shaft housing assem-
bly 5 and lock washer 6 into the lower
case, and then tighten the ring nut 7 to
the specified torque.
NOTE:
To secure the ring nut, and lock washer 6
bend one lobe into the ring nut slot, and the
other towards the gear side.
Installing the water pump and shift
rod
1. Install the shift rod assembly 1.
NOTE:
Align the slit on the shift cam 1 with the hole
in the lower case. Then install the screw 2 as
shown.
2. Install a new gasket 3, the outer plate
cartridge 4.
To Next Page
