Yamaha EF6600DE - Connecting 120 V and 240 V Devices; Using the 4-Blade Receptacle for Dual Voltage

1
– 21 –
240V
120V
120V
GR
779-017
W
X
G
Y
ç Economy control switch
Reduce the load to the specified generator rated
output if an AC switch turns off. If it turns off
again, consult a Yamaha dealer.
TIP
9 The 4-blade plug receptacle can supply both
120 V and 240 V power sources.
9 The economy control switch must be turned to
“OFF” to increase engine speed to rated r/min
when:
- using a load of 0.8 A or less.
- supplying AC120 V only from W with Y.
NOTICE
7CC-020
1
C
5. Turn the individual AC switch (N.F.B.) to “ON”.
1 I “ON”
å Individual AC switch
∫ Individual AC switch
1
A
B
1
1
B
∫ AC120 V and 240 V can be used.
7CC-F8199-15-1 11.2.21 15:56 Page 21
