CONNECTION
Alternating Current (AC)
Be sure any electric devices are turned off before
plugging them in.
9 Be sure all electric devices including the lines
and plug connections are in good condition
before connection to the generator.
9 Be sure the total load is within generator rated
output.
9 Be sure the receptacle load current is within
receptacle rated current.
1. Start the engine.
2. Plug into AC receptacle.
3. Make sure the voltage meter indicates the rated
voltage.
If the voltage meter does not indicate the rated
voltage (i.e., when using an extension cord, etc.),
use the voltage adjuster to adjust the output volt-
age to the rated voltage.
å Voltage meter
TIP
Turn the voltage adjuster clockwise or counterclock-
wise to increase or decrease output voltage.
1 Voltage adjuster
4. Turn the AC switch (N.F.B.) and economy control
switch to “ON” and turn on any electric devices.
1 I “ON”
å AC120 V can be used.
A
A
