3-23
GB
3) Place the tilt lock lever in the release
position.
EMU00290
PROCEDURE FOR TILTING UP
Manual tilt model
1) Place the gear shift lever in Neutral.
2) Remove the fuel line connection from
the motor.
4) Hold the rear of the top cowling with
one hand and fully tilt the engine up.
5) The tilt support bar turns to the
locked position automatically.
EMU00300*
PROCEDURE FOR TILTING DOWN
Manual tilt model
1) Place the tilt lock lever in the lock
position.
2) Slightly tilt up the engine until the tilt
support bar is released automatically.
3) Tilt down the engine.
402071
403052
304043
402074
