EMU01206
MAIN COMPONENTS
1 Top cowling
2 Top cowling lock lever
3 Oil drain bolt
4 Anti-cavitation plate
5 Trim tab
6 Propeller
7 Cooling water inlet
8 Trim angle adjusting rod
9 Clamp bracket
* 0 Power trim and tilt switch
* q Recoil starter handle
w Warning indicator
* e Gear shift lever
* r Tiller handle
* t Clamp screw
* y Rope attachment
* u Tilt lock lever
* i Flushing device
* o Tilt support knob
* p Remote control box
* a Fuel tank
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
