3-24
GB
EMU00296
PROCEDURE FOR TILTING UP
Power trim/tilt model
1) Remove the fuel-line connection from
the motor.
2) Push the power trim/tilt switch “UP”
until the outboard has tilted up com-
pletely.
3) Push the tilt support knob into the
clamp bracket to support the engine.
w
After tilting the engine, be sure to sup-
port it with the tilt support knob. Other-
wise, the engine could fall back down
suddenly if oil in the power trim/tilt unit
should lose pressure.
403054
UP
DN
701034*
UP
DN
EMU00305
PROCEDURE FOR TILTING DOWN
Power trim/tilt model
1) Push the power trim/tilt switch “UP”
until the engine is supported by the
tilt rod.
2) Pull out the tilt support knob.
3) Push the power trim/tilt switch “DN”
(Down) to lower the engine to the
desired position.
65W-9-77-3B (E,F,S) 3/19/02 5:21 PM Page 22
