Yamaha F20A - SPECIFICATIONS

4-1
GB
Recommended fuel
Fuel tank capacity
Recommended engine oil
Engine oil capacity (Without oil filter)
(With oil filter)
Recommended gearcase oil
Gear oil capacity
l (US. gal., Imp. gal.)
SAE
API
l (US. qt., Imp. qt.)
l (US. qt., Imp. qt.)
cm
3
(US. oz., Imp. oz.)
Spark plug
Propeller nut
Engine oil drain bolt
Engine oil filter
N•m (kgf•m, ft•lb)
N•m (kgf•m, ft•lb)
N•m (kgf•m, ft•lb)
N•m (kgf•m, ft•lb)
DIMENSIONS
PERFORMANCE
Overall Length
Overall Width
Overall Height S/L/X
Transom height S/L/X
Weight S/L/X
mm (in.)
mm (in.)
mm (in.)
mm (in.)
Kg (lb.)
Full throttle operating range
Maximum output
Idling speed (Neutral)
r/min
kW @ r/min
r/min
ENGINE
Engine type
Displacement
Bore × stroke
Ignition system
Spark plug
Spark plug gap
Valve clearance (cold engine) IN
EX
Control system
Starting system
Battery
Min. cold cranking amps (CCA/EN)
Min. rated capacity (20HR/IEC)
Alternator output
Starting carburetion system
cm
3
(cu.in.)
mm (in.)
NGK
mm (in.)
mm (in.)
mm (in.)
amps at -18°C (-0.4°F)
A·h
V-Amp (W)
DRIVE UNIT
Gear positions
Gear ratio
Trim and tilt system
Propeller mark
FUEL AND OIL
TIGHTENING TORQUE
EMU00323*
SPECIFICATIONS
Model
Unit F20AE
Item
Regular unleaded gasoline
(Minimum R.O.N.90)
24 (6.34, 5.28)/25 (6.60, 5.50)
4 stroke motor oil
10W-30, 10W-40
SE, SF, SG, SH, SJ
1.7 (1.80, 1.50)
1.9 (2.00, 1.67)
Hypoid gear oil (SAE 90)
320 (10.81, 11.27)
18 (1.8, 13)
35 (3.5, 25)
28 (2.8, 20)
18 (1.8, 13)
703 (27.7)
376 (14.8)
1,148 (45.2)/1,275 (50.2)/—
423 (16.7)/550 (21.7)/—
65 (143)/67 (148)/—
5,000–6,000
14.7 @ 5,500
875–975
4-stroke, OHC, L2
498 (30.39)
65.0 × 75.0 (2.56 × 2.95)
C.D.I system
DPR6EA-9
0.8–0.9 (0.031–0.035)
0.15–0.25 (0.006–0.010)
0.25–0.35 (0.010–0.014)
Remote control
Electric start
347
40
12-15
Prime start
Forward-Neutral-Reverse
2.08 (27/13)
Manual
F
