1-7
SPEC
Specification
Battery requirement
PTT requirement
Electrical technical data
Ignition timing control system
Item Unit
Model
F25MHA
F25EHA
Minimum cold cranking amps
CCA/SAE
A — 245.0
Minimum rated capacity
MCA/ABYC
Ah — 323.0
Minimum reserve capacity
RC/SAE
Minutes — 52
Item Unit
Model
F25EA
F25A T25A
Minimum cold cranking amps
CCA/SAE A 245.0
Minimum rated capacity
MCA/ABYC Ah 323.0
Minimum reserve capacity
RC/SAE Minutes 52
Item Unit
Model
F25EA
F25A T25A
Fluid type — ATF Dexron II
Item Unit
Model
F25MHA
F25EHA
Spark plug
Gap
mm (in) 0.8–0.9 (0.031–0.035)
Cap resistance (*1)
kΩ 5.0
Ignition coil
Primary coil resistance (*1)
at 20 °C (68 °F)
Ω 0.26–0.35
Secondary coil resistance
(*1)
(spark plug wire – spark plug
wire)
at 20 °C (68 °F)
kΩ 6.8–10.2
Pulser coil
Air gap
mm (in) 0.8 (0.031)
Resistance (*1)
at 20 °C (68 °F)
Ω 152.0–228.0
Output peak voltage
at cranking (unloaded)
V4.5
at cranking (loaded)
V2.7
at 1500 r/min (loaded)
V4.1
at 3500 r/min (loaded)
V6.5
